Vitrek V73: The Ultimate Hipot Tester for AC/DC, IR, and Low Resistance Testing - Best Price at Jansen Calibration .

Product Overview:

The Vitrek V73 Hipot Tester is a versatile and advanced testing instrument designed to perform a wide range of electrical safety tests on electrical equipment, components, and materials. It combines AC/DC hipot testing, insulation resistance (IR) testing, and low resistance testing capabilities in a single, compact unit.

Features and Specifications:

AC/DC Hipot Testing:
Voltage range: 20-5000 VDC
Current range: 0-100 mA
Test modes: Ramp, Step, Dwell, and Breakdown
Insulation Resistance Testing:
Voltage range: 50-1000 VDC
Resistance range: 0-1000 MΩ
Test modes: Timed, Ramp, and Step
Low Resistance Testing:
Current range: 0-1000 A
Resistance range: 0-100 mΩ
Test modes: 4-Wire Kelvin and 2-Wire
Color Touch LCD:
Intuitive user interface
Real-time test data display
Graphical trending and data logging
Other Features:
Built-in safety features
Remote control capability
Data storage and retrieval
Compact and portable design

What’s in the Box:

Vitrek V73 Hipot Tester
Test leads and accessories
User manual
Calibration certificate
