EC-2D-8300 Handheld Scanner

Features • Support 1D and 2D Barcode • Automatic Detect Reading Mode • 3 in 1 combo Interface - change interface by replacing cable • Colored Aiming Blue Light Specifications: Scan Type: 2D Image CMOS: 640 X 480 Motion Tolerance: Up to 450 cm/s for 13 mil UPC at optimal focus Scan Angle: Horizontal 45°; Vertical: 45° Print Contrast: 20% Minimum Reflectance Difference Pitch, Skew: 45°, 65° Decode: ALL 1D, PDF, ALL 2D Operating Temperature: 0°C to 50°C (32°F to 122°F) Storage Temperature: -40°C to 70°C (-40°F to 158°F) Humidity: 0% to 95% relative humidity, non-condensing Drop: 50 2m drops to concrete Environmental Sealing: IP54 Light Levels: 100,000 Lux Input Voltage: 5 VDC to 5.5 VDC Operating Power: 2. W (420mA @ 5 VDC) Standby Power: 0.45 W (80mA @ 5 VDC) Dimensions (L x W x H): 180×70×80 mm Weight Scanner : 150g
