Model Number:SUR3107XR

Type:FTTH Solutions

Use:FTTH

Application:FTTH FTTB FTTX Network

LAN Interface:1 x 10/100/1000Mbps(GE) and 1 x 10/100Mbps(FE)

PON Interface:1 GPON BOB Class B+/Class C+

Optical interface:SC/APC connector Single Fiber

Transmission Distance:20km

Wavelength:Tx1310nm/Rx1490nm

Power Consumption:≤6W

DC power supply:+12V,1A

Transmitting optical power:+0.5~+5dBm/+2~+7dBm

Warranty:1 Year


1. Overview

* SUR3107XR is designed as HGU (Home Gateway Unit) in different FTTH solutions. The carrier-class FTTH application provides different services access.
* SUR3107XR is based on mature and stable, cost-effective XPON technology.
* SUR3107XR adopts high reliability, easy management, configuration flexibility and good quality of service guarantees to meet the technical performance of EPON Standard of China Telecom CTC3.0 and GPON Standard of ITU-TG.984.X

2. Functional Feature
* Support EPON/GPON mode and switch mode automatically
* Support Route mode for PPPoE/IPoE/Static IP and Bridge mode
* Support IPv4 and IPv6 Dual mode
* Support 4G WIFI and 2*2 MIMO
* Support CATV interface for Video Service and remote control by Major OLT
* Support LAN IP and DHCP Server configuration
* Support Port Mapping and Loop-Detect
* Support Firewall function and ACL function
* Support IGMP Snooping/Proxy multicast feature
* Support TR069 remote configuration and maintenance
* Specialized design for system breakdown prevention to maintain stable system
3.Application
* Typical Solution：FTTH(Fiber To The Home)
* Typical Business：INTERNET、IPTV、WIFI 、CATV etc
